Commercial BESS (Cabinet Energy Storage System with PCS)
Model: ProvaArk-60KWh
Model: ProvaArk-120KWh
Model: ProvaArk-120KWh
.png/:/cr=t:0%25,l:0%25,w:100%25,h:100%25/rs=w:388,cg:true)
- INVERTER (PCS)
- Max PV Input Power: 30KW
- Rated Charge/Discharge Power: 60KW (Grid side: 30KW, Load side 30KW)
- AC INPUT
- Rated Input Voltage: 400VAC
- Grid Type: 3P4W
- Power Factor: 1 (Leading) ~ 1 (Lagging)
- PV INPUT (DC)
- Norminal/Max DC Voltage: 450VDC
- MPPT Voltage Range: 200-850 VDC
- Maximum Input Current: 100A
- MPPT Tracker: 1
- Number of PV Input Channel: 1
- GRID OUTPUT (AC)
- Rated Output Voltage: 400V±1%
- Rated Output Frequency: 50Hz
- Rated Current: 43A
- Transfer Time: 20ms
- Pure Sine Wave Output
- BATTERY MODE OUTPUT (AC)
- Norminal Output Voltage: 208/220/230/240 VAC
- System Efficiency: 85%
- BATTERY SPECIFICATIONS
- Voltage: 268.8V-864V
- Capacity: 67KWh-168KWh
- System Configuration: 1P96S - 1P 240S
- 2000 cycles @ 80% DOD, 25℃
- Dimension: 1861X2100X1267 mm
- Weight: Approx 2500kg
- IP Rating: IP55 (Battery Room); IP53 (Electrical Room)
- Seismic Intensity Rating: 8 degree (IEC60980)
- Cooling Method: Air condition (Battery Room); Force Air Cooling (Electrical Room）
- Fire Fighting System: Automatic fire extinguishing
- Fire Extinguishing Media: FM200
- Anti Corrotion Grade: C3
- Certification: CE, UN38.3
- Communication: Ethernet
- Communication Protocols: Mobus/TCP/IP
Model: ProvaArk-120KWh
Model: ProvaArk-120KWh
Model: ProvaArk-120KWh
- INVERTER (PCS)
- Max PV Input Power: 60KW
- Rated Carge/Discharge Power: 120KW (Grid side: 60KW, Load side 60KW)
- AC INPUT
- Rated Input Voltage: 400VAC
- Grid Type: 3P4W
- Power Factor: 1 (Leading) ~ 1 (Lagging)
- PV INPUT (DC)
- Norminal/Max DC Voltage: 450VDC
- MPPT Voltage Range: 200-850 VDC
- Maximum Input Current: 100A
- MPPT Tracker: 1
- Number of PV Input Channel: 1
- GRID OUTPUT (AC)
- Rated Output Voltage: 400V±1%
- Rated Output Frequency: 50Hz
- Rated Current: 86A
- Transfer Time: 20ms
- Pure Sine Wave Output
- BATTERY MODE OUTPUT (AC)
- Norminal Output Voltage: 208/220/230/240 VAC
- System Efficiency: 85%
- BATTERY SPECIFICATIONS
- Voltage: 470.4V-864V
- Capacity: 118KWh-168KWh
- System Configuration: 1P96S - 1P 240S
- Battery Configuration: 1P12S
- 2000 cycles @ 80% DOD, 25℃
- Dimension: 1861X2100X1267 mm
- Weight: Approx 2500kg
- IP Rating: IP55 (Battery Room); IP53 (Electrical Room)
- Seismic Intensity Rating: 8 degree (IEC60980)
- Cooling Method: Air condition (Battery Room); Force Air Cooling (Electrical Room）
- Fire Fighting System: Automatic fire extinguishing
- Fire Extinguishing Media: FM200
- Anti Corrotion Grade: C3
- Certification: CE, UN38.3
- Communication: Ethernet
- Communication Protocols: Mobus/TCP/IP
Model: ProvaArk-344KWh
Model: ProvaArk-120KWh
Model: ProvaArk-344KWh
- INVERTER (PCS)
- Max PV Input Power: 60KW
- Rated Carge/Discharge Power: 120KW (Grid side: 60KW, Load side 60KW)
- AC INPUT
- Rated Input Voltage: 400VAC
- Grid Type: 3P4W
- Power Factor: 1 (Leading) ~ 1 (Lagging)
- PV INPUT (DC)
- Norminal/Max DC Voltage: 450VDC
- MPPT Voltage Range: 200-850 VDC
- Maximum Input Current: 100A
- MPPT Tracker: 1
- Number of PV Input Channel: 1
- GRID OUTPUT (AC)
- Rated Output Voltage: 400V±1%
- Rated Output Frequency: 50Hz
- Rated Current: 86A
- Transfer Time: 20ms
- Pure Sine Wave Output
- BATTERY MODE OUTPUT (AC)
- Norminal Output Voltage: 208/220/230/240 VAC
- System Efficiency: 85%
- BATTERY SPECIFICATIONS
- Voltage: 470.4V-864V
- Capacity: 118KWh-168KWh
- System Configuration: 1P96S - 1P 240S
- Battery Configuration: 1P12S
- 2000 cycles @ 80% DOD, 25℃
- Dimension: 1861X2100X1267 mm
- Weight: Approx 2500kg
- IP Rating: IP55 (Battery Room); IP53 (Electrical Room)
- Seismic Intensity Rating: 8 degree (IEC60980)
- Cooling Method: Air condition (Battery Room); Force Air Cooling (Electrical Room）
- Fire Fighting System: Automatic fire extinguishing
- Fire Extinguishing Media: FM200
- Anti Corrotion Grade: C3
- Certification: CE, UN38.3
- Communication: Ethernet
- Communication Protocols: Mobus/TCP/IP
